ASUS Z9NH-D12 Series 4-25
PCI Express Settings
Enables or DisablesPCI
Express Device Relaxed
Ordering.
PCI Express Link Register Settings
ASPM Support [Disabled]
WARNING: Enabling ASPM may cause some
PCI-E device to fail
Link Training Timeout (uS) 400
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
PCI Express Link Register Settings
ASPM Support [Disabled]
Allows you to set the ASPM level.
Configuration options: [Disabled] [Auto] [Force L0s]
[Auto] BIOS auto configure.
[Disabled] Disabled ASPM.
Link Training Timeout (uS)
This defines the number of microseconds the software will wait before polling ‘Link
Training’ bit in Link Status register. The value ranges from 10 to 1000 uS.
