xii
Model Name Z9NH-D12/ FDR Z9NH-D12/ 10G Z9NH-D12
Processor / System Bus 2 * LGA 1356
Intel® Xeon® processor E5-2400 product family
QPI 6.4 / 7.2 / 8.0 GT/s
Core Logic Intel® C602-A PCH
Mellanox
ConnectX-3 FDR
Intel® C602-A PCH
Mellanox ConnectX-3
10GbE
Intel® C602-A
PCH
Form Factor Proprietary, 6.3” x 16.7
ASUS Features FAN speed control V
Rack Optimized
(Dedicated for
Rack)
V
ASWM Enterprise V
Memory Total Slots 12 (3-channel per CPU, 6 DIMM per CPU)
Voltage 1.5V/1.35V
Capacity Maximum up to 384GB
Memory Type DDR3 800/1066/1333/1600 RDIMM
DDR3 1066/1333 ECC UDIMM/ Non-ECC UDIMM
DDR3 1066/1333 LR-DIMM
Memory Size* 2GB, 4GB, 8GB, 16GB * (RDIMM)
2GB, 4GB, 8GB * (UDIMM)
8 GB, 16GB, 32GB * (LRDIMM)
Expansion
Slots
Total PCI/PCI-X/
PCI-E Slots
1 * PCI-E x16 (X16 Gen3 Link)
Storage SATA Controller Intel® C602-A:
2 SATA 3Gb/s ports; 2 SATA 6Gb/s ports
Intel® RSTe (for Windows only)
(Support software RAID 0, 1, 10 & 5)
LSI® MegaRAID (for Linux/Windows)
(Support software RAID 0, 1, 10)
4 SATA 3Gb/s ports
Intel® RSTe (for Windows only)
(Support software RAID 0, 1, 10 & 5 for all SATA ports)
SAS Controller Optional kits:
ASUS PIKE 2008 8-port SAS 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS 6G RAID card
ASUS PIKE 2108 8-port SAS 6G HW RAID card
(support with riser card)
References
Refer to the following sources for additional information, and for product and software
updates.
1. ASUS Server Web-based Management (ASWM) user guide
This manual tells how to set up and use the proprietary ASUS server
management utility.
2. ASUS websites
The ASUS websites worldwide provide updated information for all ASUS hardware
and software products. Refer to the ASUS contact information.
Conventions
To ensure that you perform certain tasks properly, take note of the following symbols
used throughout this manual.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
Keys enclosed in the less-than and greater-than
sign means that you must press the enclosed key.
Example: means that you must press
the Enter or Return key.
If you must press two or more keys simultaneously,
the key names are linked with a plus sign (+).
Example:
Command Means that you must type the command
exactly as shown, then supply the required
item or value enclosed in brackets.
Example: At the DOS prompt, type the
command line: format A:/S
DANGER/WARNING: Information to prevent injury to yourself when
trying to complete a task.
CAUTION: Information to prevent damage to the components when
trying to complete a task.
NOTE: Tips and additional information to help you complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
