xiii
Z9NH-D12 series specifications summary
(continued on the next page)
Model Name Z9NH-D12/ FDR Z9NH-D12/ 10G Z9NH-D12
Processor / System Bus 2 * LGA 1356
Intel® Xeon® processor E5-2400 product family
QPI 6.4 / 7.2 / 8.0 GT/s
Core Logic Intel® C602-A PCH
Mellanox
ConnectX-3 FDR
Intel® C602-A PCH
Mellanox ConnectX-3
10GbE
Intel® C602-A
PCH
Form Factor Proprietary, 6.3” x 16.7
ASUS Features FAN speed control V
Rack Optimized
(Dedicated for
Rack)
V
ASWM Enterprise V
Memory Total Slots 12 (3-channel per CPU, 6 DIMM per CPU)
Voltage 1.5V/1.35V
Capacity Maximum up to 384GB
Memory Type DDR3 800/1066/1333/1600 RDIMM
DDR3 1066/1333 ECC UDIMM/ Non-ECC UDIMM
DDR3 1066/1333 LR-DIMM
Memory Size* 2GB, 4GB, 8GB, 16GB * (RDIMM)
2GB, 4GB, 8GB * (UDIMM)
8 GB, 16GB, 32GB * (LRDIMM)
Expansion
Slots
Total PCI/PCI-X/
PCI-E Slots
1 * PCI-E x16 (X16 Gen3 Link)
Storage SATA Controller Intel® C602-A:
2 SATA 3Gb/s ports; 2 SATA 6Gb/s ports
Intel® RSTe (for Windows only)
(Support software RAID 0, 1, 10 & 5)
LSI® MegaRAID (for Linux/Windows)
(Support software RAID 0, 1, 10)
4 SATA 3Gb/s ports
Intel® RSTe (for Windows only)
(Support software RAID 0, 1, 10 & 5 for all SATA ports)
SAS Controller Optional kits:
ASUS PIKE 2008 8-port SAS 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS 6G RAID card
ASUS PIKE 2108 8-port SAS 6G HW RAID card
(support with riser card)
