ASUS Z9NH-D12 Series 5-27
5.3.1 Creating a RAID set
To create a RAID set
1. From the utility main menu, select 1. Create RAID Volume and press
. The following screen appears.
2. Enter a name for the RAID set and press .
3. When the RAID Level item is selected, press the up/down arrow key to select
a RAID level to create, and then press .
4. When the Disks item is selected, press to select the hard disk drives
you want to include in the RAID set. The SELECT DISKS screen appears.
5. Use the up/down arrow key to select a drive, and then press
to select. A small triangle marks the selected drive. Press after
completing your selection.
[ESC]-Previous Menu [ENTER]-Select [ ]Change
Intel(R) Rapid Storage Technology enterprise - SCU Option ROM - 3.0.0.1104
Copyright(C) 2003-11 Intel Corporation. All Rights Reserved.
[ CREATE VOLUME MENU ]
[ HELP ]
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Syne:
Create Volume
Enter a unique volume name that has no special characters and is
16 characters or less.
Volume0
RAID0(Strips)
Select Disks
128KB
0.0 GB
N/A
[TAB]-Next
[ SELECT DISKS ]
Port Drive Model Serial # Size Status
0 ST3300656SS HWAS0000991753TR 279.3GB Non-RAID Disk
1 ST3300656SS 37VN00009846RAJ1 279.3GB Non-RAID Disk
2 ST3300656SS 397600009846UEDY 279.3GB Non-RAID Disk
3 ST3300656SS GWC50000991756G6 279.3GB Non-RAID Disk
Select 1 Master and 1 Recovery disk to create volume.
[ ]-Prev/Next [TAB]-(M)aster [SPACE]-(R)ecovery [ENTER]-Done
