Zanussi ZBB29450SA - Manual (Page 23)

Remove the screw
from the lamp cover.
Remove the lamp
cover (refer to the il-
lustration).
Replace the used
lamp with a new lamp
of the same power
and specifically de-
signed for household
appliances (the maxi-
mum power is shown
on the lamp cover).
Install the lamp cover.
Tighten the screw to
the lamp cover.
Connect the plug to
the mains socket.
Open the door. Make
sure that the light
comes on.
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to "In-
stallation".
3. If necessary, replace the defective door
gaskets. Contact the Service Center.
Technical data
Dimension of the recess
Height 1780 mm
Width 560 mm
Depth 550 mm
Rising Time 24 h
Voltage 230-240 V
Frequency 50 Hz
The technical information are situated in the rat-
ing plate on the internal left side of the appli-
ance and in the energy label.
