ZANUSSI
P R O F E S S I O N A L
BUILT IN UNIT COLD ROOMS -2º+2ºC
10/11.7 m³
Shelving as accessory
Compressor power - HP 0,75 1,10 1,10
Monobloc refrigeration unit
Usable volume - m³. 10,0 11,7 11,7
Usable surface area - m² 4,93 5,74 5,74
Power supply - V, phases, Hz 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50
Net weight - kg. 479 532 532
Noise level - dBA 60 60 60
installed-electric 0.85 1.2 1.2
Power - kW
height 2030 2030 2030
depth 2030 2030 2830
width 2430 2830 2030
Internal dimensions - mm
height 2150 2150 2150
depth 2150 2150 2950
width 2550 2950 2150
External dimensions - mm
MN10020CL
102236
MN11720CL
102252
MN11728CL
102233
CHARACTERISTICS MODELS
TECHNICAL DATA
RANGE
COMPOSITION
A complete and flexible range of cold rooms
ideal for storing and conserving perishable
food (meat, fish, cold cuts, cheese, fruit,
vegetables), in addition to chilled and frozen
food. Constructed in top quality, reliable
materials, they are manufactured with the
utmost attention paid to eliminting possible
ecological damage. All models can be
connected to a refrigeration unit installed
directly inset on the wall of the cold room or
to a remote refrigeration unit. The availability
of a remote condenser unit is particularly
useful when using cold rooms in
environments with critical ambient
temperatures, ventilation or space problems.
The models detailed on this sheet are 3 cold
rooms (-2°+2°C) with built-in refrigerating
unit and with usable volume of 10 to 11,7m³
with panel insulation 60 mm in thickness. All
models come with panels and gas
precharged cooling unit.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
� Assembly system that guarantees minimal
temperature loss through twin hook fasteners
which allow perfect alignment of the panels.
This fastener is made of high resistant
composite material and guarantees perfect
grip of all components that can be easely
disassembled and reassembled
� Wall panels and inside ceiling panels are
cladded with anti-scratch prepainted
galvanized steel
� All panels are insulated with injected
polyurethane.CFC and HCFC free
� All panels have PVC gaskets foamed in
place to assure airtight and secure fitting.
Any other sealing between panels on site is
eliminated
� Galvanized steel floor covered with a
non-abrasive, non-slip, ribbed plastic coat
� Rounded internal and external corners.
� The right-hinged door is available as
standard (left-hinghed door on request) and
constructed with smooth rounded profiles,
cam-lift action highes, airtight magnetic door,
gaskets and high insulation for saving energy
and operating costs. As an option a
microswitch switches on automatically the
internal light and turns off the fans
� Newly designed handle, complete with
lock has an internal safety release to prevent
entrapment when the door is accidentally
locked from outside
� Powerful tropicalized refrigeration system
designed to operate more efficiently and
without failure in the most extreme
temperatures (up to 43ºC)
� Defrosting through heated gas permits to
reduce the total power installed shorten
defrosting time and limited warming of the
cold room
� The control panel includes: luminous
ON/OFF switch, internal lighting switch, cold
room functioning indicator, defrosting cycle
indicator, temperature and thermostat control
with digital display
� All models comply with the standards
required by the main international approval
bodies and are H marked
