11
GigaX2024B L2 Managed Switch User Manual
Enter your user name and password, and then click OK to enter the configuration
Manager. Use the following defaults the first time you log into this interface:
Default User Name: admin
Default Password: (no password)
You can change the password at any time (see section 6.3.1
System Commands.
The browser will download java applet from the switch and this
will take several seconds.
3. To setup a new IP address, click System, then IP Setup. Fill in the IP
address, network mask and default gateway, then click OK.
4. When the new address is applied to the switch, the browser can no longer
update the switch status window or retrieve any page. You need to retype
the new IP address in the address/location box, and press , then the
Web link returns.
Figure 7. IP setup
Note
