1-10 Chapter 1: Product Introduction
1.7 System memory
1.7.1 Overview
The motherboard comes with two Double Data Rate (DDR) Dual Inline Memory
Module (DIMM) sockets. These sockets support up to 2GB system memory using
184-pin PC3200/PC2700/PC2100 unbuffered DDR DIMMs and allow up to 3.2 GB/s
data transfer rate.
The following figure illustrates the location of the DDR DIMM sockets.
1.7.2 Memory configurations
You may install 64 MB, 128 MB, 256 MB, 512 MB, and 1 GB DDR DIMMs into the
DIMM sockets.
For optimum compatibility, we recommend that you obtain memory modules
from qualified vendors. See the Qualified Vendors List (QVL) on the next page.
K8V-VM ULTRA
K8V-VM ULTRA 184-pin DDR DIMM sockets
DIMM1 DIMM2
r
R
K8V-VM ULTRA
