4.5.6

Hardware Monitor

Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit

Hardware Monitor

CPU Temperature

[51ºC/122.5ºF]

MB Temperature

[41ºC/105.5ºF]

Power Temperature

[51ºC/122.5ºF]

CPU Q-Fan Control

[Disabled]

CPU Fan Speed

[3813 RPM]

Chassis Fan Speed

[N/A]

Power Fan Speed

[N/A]

VCORE Voltage

[ 1.320V]

3.3V Voltage

[ 3.345V]

5V Voltage

[ 5.094V]

12V Voltage

[11.880V]

CPU Temperature [xxxC/xxxF]

CPU Temperature [xxxC/xxxF]
MB Temperature [xxxC/xxxF]

MB Temperature [xxxC/xxxF]

MB Temperature [xxxC/xxxF]
Power Temperature [xxxC/xxxF]

Power Temperature [xxxC/xxxF]

The onboard hardware monitor automatically detects and displays the
motherboard, power supply unit and CPU temperatures. Select Ignored if
you do not wish to display the detected temperatures.

CPU Q-Fan Control [Disabled]

Allows you to enable or disable the ASUS Q-Fan feature that smartly
adjusts the fan speeds for more efficient system operation. When this field
is set to [Enabled], the C P U F a n R a t i o

C P U F a n R a t i o

C P U F a n R a t i o and P o w e r F a n S p e e d

P o w e r F a n S p e e d

P o w e r F a n S p e e d items

appears to allow selection of the appropriate fan speed ratio.
Configuration options: [Disabled] [Enabled]

CPU Fan Ratio [Auto]

Allows you to select the appropriate CPU fan speed ratio for the system.
The default [Auto] automatically selects the fan speed ratio when
operating a low CPU temperature. Select a higher ratio if you installed
additional devices and the system requires more ventilation. This item
appears only when the CPU Q-Fan Control item is Enabled.
Configuration options: [Auto] [90%] 80%] [70%] [60%] [40%] [30%]
[20%]

CPU Target Temperature [xxxºC]

Allows you to set the CPU temperature threshold when the CPU fan speed
is increased to lower the CPU temperature. This item appears only when
the CPU Q-Fan Control item is Enabled. The configuration option varies
depending on the CPU installed.
