4 - 2 4 4 - 2 4 4 - 2 4 4 - 2 4 4 - 2 4 C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p
4.4.4 4.4.4 4.4.4 4.4.4 4.4.4 Onboard Devices Configuration Onboard Devices Configuration Onboard Devices Configuration Onboard Devices Configuration Onboard Devices Configuration
Onboard AC’97 Audio [Auto]
Onboard LAN [Enabled]
Onboard LAN Boot ROOM [Disabled]
Serial Port1 Address [3F8/IRQ4]
Parallel Port Address [378]
Parallel Port Mode [ECP]
ECP Mode DMA Channel [DMA3]
Parallel Port IRQ [IRQ7]
Onboard Game/MIDI Port [200/330]
OnBoard AC’97 Audio [Auto] OnBoard AC’97 Audio [Auto] OnBoard AC’97 Audio [Auto] OnBoard AC’97 Audio [Auto] OnBoard AC’97 Audio [Auto]
[Auto] allows the BIOS to detect whether you are using any audio device. If
an audio device is detected, the onboard audio controller is enabled; if no
audio device is detected, the controller is disabled.
Configuration options: [Disabled] [Auto]
OnBoard LAN [Enabled] OnBoard LAN [Enabled] OnBoard LAN [Enabled] OnBoard LAN [Enabled] OnBoard LAN [Enabled]
Allows you to enable or disable the onboard LAN controller.
Configuration options: [Disabled] [Enabled]
OnBoard LAN Boot ROM [Disabled]
Allows you to enable or disable the option ROM in the onboard LAN
controller. This item appears only when the Onboard LAN item is set
to Enabled. Configuration options: [Disabled] [Enabled]
Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]
[2F8/IRQ3]
