Visit the ASUS website (www.asus.com) for the latest DDR 400 Qualified
Vendors List.
Memory frequency/CPU FSB synchronization Memory frequency/CPU FSB synchronization Memory frequency/CPU FSB synchronization Memory frequency/CPU FSB synchronization Memory frequency/CPU FSB synchronization
This motherboard supports different memory frequencies depending on the
CPU FSB (Front Side Bus) and the type of DDR DIMM.
Recommended memory configurations Recommended memory configurations Recommended memory configurations Recommended memory configurations Recommended memory configurations
* For dual-channel configuration (3), you may:
• install identical DIMMs in all four sockets
• install identical DIMM pair in DIMM_A1 and DIMM_B1 (blue sockets)
and identical DIMM pair in DIMM_A2 and DIMM_B2 (black sockets)
• install same size DIMMs in DIMM_A1 and DIMM_B1 (blue sockets) and
another same size pair in DIMM_A2 and DIMM_B2 (black sockets)
S o c k e t s S o c k e t s S o c k e t s S o c k e t s S o c k e t s
M o d e M o d e M o d e M o d e M o d e D I M M _ A 1 D I M M _ A 1 D I M M _ A 1 D I M M _ A 1 D I M M _ A 1 D I M M _ A 2 D I M M _ A 2 D I M M _ A 2 D I M M _ A 2 D I M M _ A 2 D I M M _ B 1 D I M M _ B 1 D I M M _ B 1 D I M M _ B 1 D I M M _ B 1 D I M M _ B 2 D I M M _ B 2 D I M M _ B 2 D I M M _ B 2 D I M M _ B 2
( b l u e ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l a c k ) ( b l a c k ) ( b l a c k ) ( b l a c k ) ( b l a c k ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l u e ) ( b l a c k ) ( b l a c k ) ( b l a c k ) ( b l a c k ) ( b l a c k )
Single-channel (1) Populated — — —
(2) — Populated — —
(3) — — Populated —
(4) — — — Populated
Dual-channel (1) Populated — Populated —
(2) — Populated — Populated
(3) *Populated Populated Populated Populated
C P U F S B C P U F S B C P U F S B C P U F S B C P U F S B D D R D I M M T y p e D D R D I M M T y p e D D R D I M M T y p e D D R D I M M T y p e D D R D I M M T y p e M e m o r y F r e q u e n c y M e m o r y F r e q u e n c y M e m o r y F r e q u e n c y M e m o r y F r e q u e n c y M e m o r y F r e q u e n c y
800 MHz PC3200/PC2700/PC2100 400/320*/266 MHz
533 MHz PC2700/PC2100 333/266 MHz
*When using 800 MHz FSB CPU, PC2700 DDR DIMMs run only at 320MHz
(not 333MHz) due to chipset limitation.
