A S U S P 5 W D 2 A S U S P 5 W D 2 A S U S P 5 W D 2 A S U S P 5 W D 2 A S U S P 5 W D 2 2 - 3 7 2 - 3 7 2 - 3 7 2 - 3 7 2 - 3 7
I m p o r t a n t n o t e s o n m o t h e r b o a r d p o w e r r e q u i r e m e n t s I m p o r t a n t n o t e s o n m o t h e r b o a r d p o w e r r e q u i r e m e n t s I m p o r t a n t n o t e s o n m o t h e r b o a r d p o w e r r e q u i r e m e n t s I m p o r t a n t n o t e s o n m o t h e r b o a r d p o w e r r e q u i r e m e n t s I m p o r t a n t n o t e s o n m o t h e r b o a r d p o w e r r e q u i r e m e n t s
• For a fully configured system, we recommend that you use a power
supply unit (PSU) that complies with ATX 12 V Specification 2.0 (or
later version) and provides a minimum power of 400 W.
• Do not forget to connect the 8-pin/4-pin EATX12 V power plug;
otherwise, the system will not boot up.
• Make sure that the PSU can support at least 8 A on the +12V_1
lead and 13 A on the +12V_2 lead.
• The ATX 12 V Specification 2.0-compliant (400 W) PSU has been
tested to support the motherboard power requirements with the
following configuration:
CPU : Intel ® Pentium ® 4 3.73 GHz Extreme Edition
Memory : 512 MB DDR2 (x 4)
Graphics card : PCI Express x16 Nvidia 6600GT
Parallel ATA device : IDE hard disk drive
Serial ATA device : SATA hard disk drive (x2)
Optical drives : DVD-RW
• Use of a PSU with a higher power output is recommended when
configuring a system with more power consuming devices. The
system may become unstable or may not boot up if the power is
inadequate.
• If you want to use two high-end PCI Express x16 graphics cards, use
a PSU with 450 to 500 W power to ensure system stability.
• To support an Intel ® Dual-Core CPU up to 840 Extreme Edition, make
sure that the PSU can provide at least DC 16A (peak 22A) on the
+12V_2 lead. The vendors list on the next page is provided for your
reference.
Power Supply Unit Reference Vendors List Power Supply Unit Reference Vendors List Power Supply Unit Reference Vendors List Power Supply Unit Reference Vendors List Power Supply Unit Reference Vendors List
V e n d o r V e n d o r V e n d o r V e n d o r V e n d o r M o d e l M o d e l M o d e l M o d e l M o d e l M a x . P o w e r ( W ) M a x . P o w e r ( W ) M a x . P o w e r ( W ) M a x . P o w e r ( W ) M a x . P o w e r ( W )
ASUS A-40GA 400
Delta GPS-400AA-100 A 400
Hipro HP-E4008FWR 400
Delta GPS-450AA-100 A 450
ASUS A-45GA 450
AcBel API4PC04 450
Seventeam ST-460EAD-05F 460
AcBel API4PC23 500
AcBel API4PC24 550
