A S U S P 5 W D 2 A S U S P 5 W D 2 A S U S P 5 W D 2 A S U S P 5 W D 2 A S U S P 5 W D 2 2 - 2 5 2 - 2 5 2 - 2 5 2 - 2 5 2 - 2 5
2.5.5 2.5.5 2.5.5 2.5.5 2.5.5 PCI slots PCI slots PCI slots PCI slots PCI slots
The PCI slots support cards such as
a LAN card, SCSI card, USB card, and
other cards that comply with PCI
specifications. The figure shows a
LAN card installed on a PCI slot.
2.5.6 2.5.6 2.5.6 2.5.6 2.5.6 PCI Express x1 slot PCI Express x1 slot PCI Express x1 slot PCI Express x1 slot PCI Express x1 slot
This motherboard supports PCI
Express x1 network cards, SCSI
cards and other cards that comply
with the PCI Express specifications.
The following figure shows a
network card installed on the PCI
Express x1 slot.
