2 - 6 2 - 6 2 - 6 2 - 6 2 - 6 C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n
I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s P a g e P a g e P a g e P a g e P a g e
1. Floppy disk drive connector (34-1 pin FLOPPY) 2-29
2. ITE IDE connectors (40-1 pin PRI_EIDE [red], 2-29
SEC_EIDE [red]
3. ICH7R Primary IDE connector (40-1 pin PRI_IDE) 2-30
4. ICH7R Serial ATA connectors (7-pin SATA1 [red], 2-31
SATA2 [red], SATA3 [black], SATA4 [black])
5. Optical drive audio connector (4-pin CD) 2-32
6. Front panel audio connector (10-1 pin AAFP) 2-32
7. USB connectors (10-1 pin USB56, USB78) 2-33
8. GAME/MIDI port connector (16-1 pin GAME) 2-33
9. Chassis intrusion connector (4-1 pin CHASSIS) 2-34
10. CPU, Chassis, and Power fan connectors 2-35
(4-pin CPU_FAN, 3-pin PWR_FAN, 3-pin CHA_FAN1,
3-pin CHA_FAN2)
11. Serial port connector (10-1 pin COM1) 2-34
12. ATX power connectors (24-pin EATXPWR, 2-36
2 x 4-pin EATX12V, 4-pin EZ_PLUG)
13. System panel connector (20-pin PANEL) 2-38
• System power LED (Green 3-pin PLED)
• Hard disk drive activity LED (Red 2-pin IDE_LED)
• System warning speaker (Orange 4-pin SPEAKER)
• ATX power button/soft-off button (Yellow 2-pin PWRSW)
• Reset button (Blue 2-pin RESET)
