ROG Maximus Formula (Special Edition) / Maximus Formula 2-39
2.8.4 Installing Fusion Block System accessory
Install your watercooling system to the motherboard using the bundled accessories
to obtain the best thermal solution.
Package contents
1 2
For watercooling system with 3/8” ID tubes
1. Firmly press a tube clip and fit the tube into the clip.
2. Press the clip and connect the tube to the waterblock. When done, release
the clip to tighten the two together.
3. Repeat Step 1 and 2 for another tube. Make sure that both tubes are well
connected to prevent leak, and then fill the coolant into the reservoir.
3/8” ID tubes x 2 1/2” to 3/8” ID fittings x 2 10mm to 3/8” ID fittings x 2
1/2” ID tube clips x 2 3/8” ID tube clips x 6
