Asus Maximus Formula - Manual (Page 103)

ROG Maximus Formula (Special Edition) / Maximus Formula 4-31
4.6.6 Hardware Monitor
v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.
Select Screen
Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
Hardware Monitor
CPU Temperature [38.5ºC/102ºF]
MB Temperature [36ºC/96.5ºF]
NB Temperature [35ºC/95ºF]
SB Temperature [43ºC/109ºF]
OPT1 Temperature [N/A]
OPT2 Temperature [N/A]
OPT3 Temperature [N/A]
COP EX
NB Overheat Protection [90ºC]
SB Overheat Protection [90ºC]
OPT_TEMP1 Overheat Protection [90ºC]
OPT_TEMP2 Overheat Protection [90ºC]
OPT_TEMP3 Overheat Protection [90ºC]
CPU Fan and Chassis Fan
OPT Q-Fan and Power Fan
CPU Temperature
BIOS SETUP UTILITY
Power
v02.61 (C)Copyright 1985-2007, American Megatrends, Inc.
Scroll down to see more items.
v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.
Select Screen
Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2007, American Megatrends, Inc.
VCORE Voltage [ 1.288V]
CPU PLL Voltage [ 1.600V]
North Bridge Voltage [ 1.264V]
DRAM Voltage [ 1.568V]
FSB Termination Voltage [ 1.232V]
South Bridge Voltage [ 1.072V]
DDR3 Controller REF Voltage [ 0.784V]
SB 1.5V Voltage [ 1.520V]
3.3V Voltage [ 3.264V]
5V Voltage [ 5.064V]
12V Voltage [12.208V]
CPU Temperature; MB Temperature; NB Temperature;
SB Temperature; OPT1/2/3 Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU,
motherboard, northbridge, southbridge, and the assigned device temperatures.
Select [Ignored] if you do not wish to display the detected temperatures.
NB Overheat Protection; SB Overheat Protection [90ºC]
The system automatically shuts down when the northbridge or southbridge chipset
is heated over the set temperature to protect it from damage.
Configuration optitons: [Disabled] [70ºC] [80ºC] [90ºC]
OPT_TEMP1/2/3 Overheat Protection [90ºC]
Allows you to set the temperature over which the system automatically shuts down
when any of the thermal sensor cables connected to the motherboard detects
device overheat to protect the device from damage.
Configuration optitons: [Disabled] [50ºC] [60ºC] [70ºC] [80ºC] [90ºC]
