ASUS P5L-MX/IPAT 2-15
Serial Port Configuration
Enable or Disable
Serial Port(COM)
Serial Port Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4;
Change Settings [Auto]
Device Mode [Normal]
Serial Port [Enabled]
Allows you to enable or disable the Serial Port (COM).
Configuration options: [Disabled] [Enabled]
Change Settings [Auto]
Allows you to select an optimal settings for the super IO device.
Configuration options: [Auto] [IO=3F8h; IRQ=4;] [IO=3F8h; IRQ=3,
4, 5, 6, 7, 10, 11,12;] [IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11,12;]
[IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11,12;] [IO=2E8h; IRQ=3, 4, 5, 6, 7,
10, 11,12;]
Device Mode [Normal]
Allows you to set the mode of Serial Port.
Configuration options: [Normal] [High Speed]
Parallel Port Configuration
Enable or Disable
Parallel Port(LPT/
LPTE)
Parallel Port Configuration
Parallel Port [Enabled]
Device Settings IO=378h; IRQ=5;
Change Settings [Auto]
Device Mode [STD Printer Mode]
Parallel Port [Enabled]
Allows you to enable or disable the Parallel Port (LPT/LPTE).
Configuration options: [Disabled] [Enabled]
Change Settings [Auto]
Allows you to select an optimal settings for the super IO device.
Configuration options: [Auto] [IO=378h; IRQ=5;] [IO=378h; IRQ=5, 6,
7, 10, 11,12;] [IO=278h; IRQ=5, 6, 7, 10, 11,12;] [IO=3BCh; IRQ=5,
6, 7, 10, 11,12;]
