Page 20

1-14

Chapter 1

NOTE

A CF card fits only in one orientation, and slides smoothly into
the slot if inserted correctly. DO NOT force the card into the
slot!

Installing and removing a CF card

To install a CF card:

1. With the label side (usually the side with the card manufacturer’s

name) face up, and the barcode/serial number side face down, insert
the 50-pin female connector of the card into the CF card slot.

2. Push the card all the way into the slot until it fits completely. If properly

installed, the CF card edge aligns with the top edge of the device.

To remove a CF card:

Simply pull out the card from the slot.

Label side
