1-12 Chapter 1
Connecting the AC adapter
IMPORTANT You need to charge the battery before using the device for
the first time.
To connect the AC adapter without the cradle:
1. Connect the power cable to the jack on the sync cable adapter.
2. Connect the 26-pin device plug of the sync cable to the 26-pin
connector on the bottom of the device.
3. Connect the power plug to a grounded wall socket.
To connect the AC adapter with the cradle:
1. Connect the power
cable to the
connector at the back
of the cradle.
2. Connect the power
plug to a grounded
wall socket.
NOTE The power LED (green) blinks and starts charging the battery
as soon as you connect the power cable to a power source.
See page 2-25 on how to display the battery power status.
1
2
RESE T
Pocket PC
AC adapter/ Power cable
USB sync cable
Sync cable adapter
26-pin device plug
1
2
3
