A S U S T e r m i n a t o r T 1 C 3 b a r e b o n e s y s t e m

4 - 9

8 .

S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 [ b l a c k ] ,

S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 [ b l a c k ] ,
S A T A 2 [ b l a c k ] )

S A T A 2 [ b l a c k ] )

These connectors are for the Serial ATA signal cables for Serial ATA
hard disk drives.

You must install Windows

2000 Service Pack 4 or the Windows

Service Pack 1 before using Serial ATA hard disk drives. The Serial ATA
RAID feature (RAID 0/RAID 1) is available only if you are using Windows

2000/XP.

C3V

C3V SATA connectors

SATA2

GND

RSA

TA_TXP2

RSA

TA_TXN2

GND

RSA

TA_RXP2

RSA

TA_RXN2

GND

SATA1

GND

RSA

TA_TXP1

RSA

TA_TXN1

GND

RSA

TA_RXP1

RSA

TA_RXN1

GND

9 .

D i g i t a l a u d i o c o n n e c t o r ( 4 - 1 p i n S P D I F _ O U T )

D i g i t a l a u d i o c o n n e c t o r ( 4 - 1 p i n S P D I F _ O U T )
This connector is for an additional Sony/Philips Digital Interface
(S/PDIF) port(s). Connect the S/PDIF module cable to this connector,
then install the module to a slot opening at the back of the system
chassis.

The S/PDIF module is purchased separately.

C3V

C3V Digital audio connector

+5V

SPDIFOUT

GND

SPDIF_OUT
