2-6 Chapter 2: Hardware information
2.2.4 Layout contents
Slots/Socket Page
1. CPU sockets 2-7
2. DDR3 sockets 2-12
Onboard LEDs Page
1. Baseboard Management Controller LED (BMC_LED1) 2-19
2. CPU Warning LED (ERR_CPU) 2-19
3. DIMM Warning LED (ERR_DIMM) 2-20
4. CATT Error LED (CATTERR_LED1) 2-20
5. Q-Code LED (LED1) 2-21
Jumpers Page
1. Clear RTC RAM (CLRTC1) 2-24
2. VGA controller setting (3-pin VGA_SW1) 2-25
3. LAN controller setting (3-pin LAN_SW1, LAN_SW2) 2-25
4. LSI MegaRAID or Intel RSTe selection jumper (3-pin RAID_SEL1) 2-26
5. ME firmware force recovery setting (3-pin ME_RCVR1) 2-26
6. DDR3 thermal event setting (3-pin DIMMTRIP1) 2-27
7. PMBus 1.2 PSU select jumper (3-pin SMART_PSU1) 2-27
Internal connectors Page
1. Serial ATA 6.0/3.0 Gb/s connectors
(7-pin SATA6G 1–2 [light blue]; 7-pin SATA3G 3–6 [black])
2-30
2. PSAS connectors (PIKE required) 2-31
3. Hard disk activity LED connector (4-pin HDLED1) 2-31
4. USB connectors (10-1 pin USB34, USB56; A-Type USB10) 2-32
5. Serial port connector (10-1 pin COM2) 2-32
6. Serial General Purpose Input/Output connectors (6-1 pin
SGPIO1, 8-1 pin PSGPIO 1/2)
2-33
7. TPM connector (20-1 pin TPM1) 2-34
8. CPU, front and rear fan connectors (4-pin CPU_FAN1,
FRNT_FAN1–4, REAR_FAN1)
2-34
9. EATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1) 2-35
10. Power Supply SMBus connector (5-pin PSUSMB1) 2-36
11. System panel connector (20-1 pin PANEL1) 2-37
12. Auxiliary panel connector (20-2 pin AUX_PANEL1) 2-38
