I n t e r n a l c o n n e c t o r s
I n t e r n a l c o n n e c t o r s
I n t e r n a l c o n n e c t o r s
I n t e r n a l c o n n e c t o r s
I n t e r n a l c o n n e c t o r s
P a g e
P a g e
P a g e
P a g e
P a g e
1.
Floppy disk drive connector (34-1 pin FLOPPY)
2-23
2.
IDE connectors (40-1 pin PRI_IDE, 40-1 pin SEC_IDE)
2-23
3.
Serial ATA connectors (7-pin SATA1 [red], SATA2 [red],
SATA3 [black], SATA4 [black])
2-24
4.
Silicon Image Serial ATA RAID connector (7-pin SATA_RAID 2)
2-26
5.
CPU, Chassis, and Power fan connectors
2-27
(3-pin CPU_FAN, 3-pin CHA_FAN1, 3-pin CHA_FAN2, 3-pin PWR_FAN )
6.
USB connectors (10-1 USB56, USB78_WFG)
2-28
7.
Power connectors (24-pin EATXPWR, 4-pin ATX12V)
2-28
8.
GAME/MIDI port connector (16-1 pin GAME)
2-29
9.
Serial port connector (10-1 pin COM1)
2-30
10. IEEE 1394a connectors (10-1 pin IE1394_1; 10-1 pin IE1394_2)
2-30
11. Chassis intrusion connector (4-1 pin CHASSIS)
2-31
12. Front panel audio connector (10-1 pin AAFP)
2-32
13. Audio connector (4-pin CD [black])
2-32
14. System panel connectors (20-1 pin PANEL)
2-33
- System Power LED (Green 3-pin PLED)
- Hard Disk activity (Red 2-pin IDE_LED)
- System warning speaker (Orange 4-pin SPEAKER)
- Power/Soft-off button(Yellow 2-pin PWRSW)
- Reset switch (Blue 2-pin RESET)
