vi
H81T specifications summary
(continued on the next page)
CPU LGA1150 socket for Intel ® 4th Generation Core™ i7 / i5 / i3, Pentium ® , and
Celeron ® processors
Supports 22nm CPU*
Supports Intel
® Turbo Boost Technology 2.0**
* Up to 65W Thermal Design Power support for Intel ® standard thin mini-ITX
heatsink. Up to 84W Thermal Design Power support for standard 1150/1155
heatsink.
** Intel ® Turbo Boost Technology 2.0 support depends on the CPU type.
*** Refer to www.asus.com for Intel ® CPU support list.
Chipset Intel ® H81 Express Chipset
Memory 2 x SO-DIMMs, max. 16GB, DDR3 1600 / 1333 / 1066 MHz, non-ECC,
un-buffered memory
Dual-channel memory architecture
* Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List).
** When you install a total memory of 4GB capacity or more, Windows
® 32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows ® 32-bit operating
system.
Graphics Integrated graphics processor
Multi-VGA output support: HDMI / DVI-I / LVDS
- Supports DVI-I with max. resolution of 1920 x 1200@60Hz
- Supports HDMI with max. resolution of 4096 x 2160 @24Hz / 2560 x
1600 @60Hz
- Supports LVDS with max. resolution of 1920 x 1200 @60Hz
Maximum shared memory of 1024 MB
Expansion slots 1 x mini PCIe (half length)
Package contents
Check your motherboard package for the following items.
Motherboard ASUS H81T motherboard
Cables 1 x Serial ATA 6.0 Gb/s cable, 1 x Serial ATA 3.0 Gb/s cable, 1 x SATA power cable
Accessories 2 x I/O Shield (1 x mini-ITX, 1 x thin mini-ITX)
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
