2-24 Chapter 2: Getting started
CPU C states [Auto]
[Auto]
Automatic configuration.
[Enabled] Enables the CPU C states.
[Disabled] Disables the CPU C states.
The following items appear only when you set the CPU C states to [Enabled].
Enhanced C1 state [Enabled]
[Enabled] Enables enhanced C1 state.
[Disabled] Disables enhanced C1 state.
CPU C3 Report [Enabled]
Allows you to disable or enable the CPU C3 report to OS. Configuration
options: [Enabled] [Disabled]
CPU C6 report [Enabled]
Allows you to disable or enable the CPU C6 report to OS. Configuration
options: [Enabled] [Disabled]
C6 Latency [Short]
Allows you to choose short or long latency for C6. Configuration options:
[Short] [Long]
CPU C7 report [CPU C7s]
Allows you to disable or enable the CPU C7 report to OS. Configuration
options: [Disabled] [CPU C7] [CPU C7s]
C7 Latency [Long]
Allows you to choose short or long latency for C6. Configuration options:
[Short] [Long]
Package C State Support [Auto]
Allows you to disable or enable the whole C-State package support.
Configuration options: [Auto] [Enabled] [C0/C1] [C2] [C3] [C6] [CPU C7]
[CPU C7s]
2.6.3 PCH Configuration
PCI Express Configuration
DMI Link ASPM Control [Auto]
Allows you to control the Active State Power Managemennt on both NB and SB side of
the DMI Link. Configuration options: [Auto] [Enabled] [Disabled]
ASPM Support [Disabled]
Allows you to set the ASPM support. Configuration options: [Disabled] [Auto] [L0s] [L1]
L0sL1].
PCIe Speed [Auto]
Allows you to select the PCI Express port speed. Configuration options: [Auto] [Gen1]
[Gen2]
