ASUS P5N-D

4-33

4.5.4

Hardware Monitor

The items in this sub-menu displays the hardware monitor values automatically
detected by the BIOS. It also allows you to change CPU Q-Fan feature-related
parameters. Select an item then press to display the configuration options.

Select Menu

Item Specific Help

Press [Enter] to

enable or disable

Phoenix-Award BIOS CMOS Setup Utility

Power

F1:Help ���

���

: Select Item -/+: Change Value

F5: Setup Defaults

ESC: Exit ��

��

: Select Menu Enter: Select SubMenu

F10: Save and Exit

Hardware Monitor

CPU Q-Fan Control

[Disabled]

x CPU Q-Fan Profile

Performance

Chassis Q-Fan Control

[Disabled]

x Chassis Q-Fan Profile

Performance

Vcore Voltage

[ 1.34V]

3.3V Voltage

[ 3.20V]

5V Voltage

[ 4.83V]

12V Voltage

[11.52V]

CPU Temperature

48ºC

M/B Temperature

36ºC

CPU Fan Speed

2667 RPM

CHA_FAN1 Speed

0 RPM

CHA_FAN2 Speed

0 RPM

PWR_FAN Speed

0 RPM

CPU Fan Speed Warning

[600 RPM]

CPU Q-Fan Control [Enabled]

Allows you to enable or disable the CPU Q-Fan controller.
Configuration options: [Disabled] [Enabled]

The

CPU Fan Profile item becomes user-configurable when you enable the

CPU Q-Fan Control feature.

CPU Q-Fan Profile [Performance]

Allows you to set the appropriate performance level of the CPU Q-Fan. When
set to [Optimal], the CPU fan automatically adjusts depending on the CPU
temperature. Set this item to [Silent Mode] to minimize fan speed for quiet CPU fan
operation, or [Performance Mode] to achieve maximum CPU fan speed.
Configuration options: [Performance] [Optimal] [Silent]

[Optimal] [Silent]

Chassis Q-Fan Control [Enabled]

Allows you to enable or disable the Chassis Q-fan.
Configuration options: [Disabled] [Enabled]

The

Chassis Q-Fan Profile item becomes user-configurable when you enable

the Chassis Q-Fan Control feature.

Chassis Q-Fan Profile [Performance]

Allows you to set the appropriate performance level of the Chassis Q-Fan.
Configuration options: [Performance] [Optimal] [Silent]

[Optimal] [Silent]
