ASUS P5N-D 4-27
F1:Help ��� : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit ��: Select Menu Enter: Select SubMenu F10: Save and Exit
Select Menu
Item Specific Help
Press [Enter] to set.
Onboard Device Configuration
IDE Function Setup
NVRAID Configuration
HD Audio [Enabled] HD Audio [Enabled]
Front Panel Support Type [HD Audio]
Onboard nVidia LAN [Enabled]
Onboard LAN Boot ROM [Disabled]
Onboard 1394 [Enabled] Onboard 1394 [Enabled]
Serial Port1 Address [3F8/IRQ4]
Parallel Port Address [378/IRQ7]
Parallel Port Mode [EPP]
x ECP Mode Use DMA 3
Phoenix-Award BIOS CMOS Setup Utility
Advanced
4.4.6 Onboard Device Configuration
IDE Function Setup
This sub-menu contains IDE function-related items. Select an item then press
to edit.
Select Menu
Item Specific Help
Disable/Enable Onchip
IDE Channel0
Phoenix-Award BIOS CMOS Setup Utility
Advanced
IDE Function Setup
OnChip IDE Channel0 [Enabled]
OnChip IDE Channel1 [Enabled]
IDE DMA transfer access [Enabled]
SATA Port 1, 2 [Enabled]
SATA DMA transfer [Enabled]
SATA Port 3, 4 [Enabled]
SATA2 DMA transfer [Enabled]
IDE Prefetch Mode [Enabled]
OnChip IDE Channel0 [Enabled]
OnChip IDE Channel1 [Enabled]
Allows you to enable or disable the onchip IDE channel 0/1 controller .
Configuration options: [Disabled] [Enabled]
IDE DMA transfer access [Enabled]
Allows you to enable or disable the IDE DMA transfer access.
Configuration options: [Disabled] [Enabled]
SATA Port 1, 2 [Enabled]
Allows you to enable or disable the onchip SATA1/SATA2 port.
Configuration options: [Disabled] [Enabled]
SATA DMA transfer access [Enabled]
Allows you to enable or disable the SATA DMA transfer access.
Configuration options: [Disabled] [Enabled]
