ASUS P5N-D 4-21
HT Voltage [Auto]
Configuration options: [Auto] [1.20V] [1.22V] [1.24V]...[1.94V] [1.96V]
NB Chipset Voltage [Auto]
Configuration options: [Auto] [1.20V] [1.22V] [1.24V]...[1.74V] [1.76V]
SB Chipset Voltage [Auto]
Configuration options: [Auto] [1.50V] [1.52V] [1.54V]...[1.84V] [1.86V]
FSB & Memory Config
This sub-menu allows you to adjust the system frequency-related items. Select an
item, then press to edit.
Select Menu
Item Specific Help
System clock mode
[Auto]
Set FSB and memory speed
automatically.
[Linked]
Enter FSB speed manually.
Memory Speed changes
proportionally.
[Unlinked]
Enter FSB and memory speed
manually.
F1:Help ��� : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit ��: Select Menu Enter: Select SubMenu F10: Save and Exit
Phoenix-Award BIOS CMOS Setup Utility
Main Advanced Power Boot Tools Exit
FSB - Memory Clock Mode [Linked]
FSB - Memory Ratio [Auto]
FSB (QDR), MHz [800]
Actual FSB (QDR), MHz 800.0
x MEM (DDR), MHz Linked
Actual MEM (DDR), MHz 800.0
FSB - Memory Clock Mode [Auto]
Allows you to set the system clock mode.
Configuration options: [Auto] [Linked] [Unlinked]
The following items become user-configurable when you set the FSB-Memory
Clock Mode item to [Linked].
FSB - Memory Ratio [Auto]
Configuration options: [Auto] [1:1] [5:4] [3:2] [Sync Mode]
FSB (QDR), MHz [800]
Allows you to set the CPU FSB frequency. Adjust the value using <+> / <-> or the
numeric keypad and press .
Configuration options: [533 MHz]~[3000 MHz]
Actual FSB (QDR), MHz 800.0
The Actual FSB (QDR) reflects the actual CPU frequency that will take
effect on a reboot.
The following item becomes user-configurable when you set the FSB-Memory
Clock Mode item to [Unlinked].
