1.5 Expansion slots
In the future, you may need to install expansion cards. Refer to the technical documentation
that comes with your expansion card for installation details.
Ensure to unplug the power cord before adding or removing expansion cards. Failure to do
so may cause you physical injury and damage motherboard components.
1.5.1 PCI slots
The PCI slots support cards such as LAN cards, SCSI cards, USB cards, and other cards
that comply with the PCI specifications.
1.5.2 PCI Express x1 slot
This motherboard supports PCI Express x1 network cards, SCSI cards, and other cards that
comply with the PCI Express specifications.
1.5.3 PCI Express x16 slot
This motherboard supports PCI Express x16 graphics cards that comply with the PCI
Express specifications.
SS: Single-sided / DS: Double-sided
DIMM support:
• A*: Supports one module inserted into either slot as the single-channel memory
configuration.
• B*: Supports one pair of modules inserted into both the yellow slots as one pair of
dual-channel memory configuration.
Visit the ASUS website at www.asus.com for the latest QVL.
DDR2-667MHz capability
Vendor Part No. Size
SS/
DS
Chip No. CL Chip Brand
DIMM
support
A* B*
ADATA M2OAD5G314170Q1C58 1G DS AD29608A8A-3EG80814 N/A ADATA • •
ADATA M2OAD5H3J4170I1C53 2G DS AD20908A8A-3EG 30724 N/A ADATA • •
Apacer 78.01G9O.9K5 1G SS AM4B5808CQJS7E0751C 5 Apacer • •
Apacer 78.A1G9O.9K4 2G DS AM4B5808CQJS7E0749B 5 Apacer • •
Corsair VS1GB667D2 1G DS MID095D62864M8CEC N/A Corsair • •
G.SKILL F2-5300CL5D-4GBMQ 4G(kit of 2) DS Heat-Sink Package 5-5-5-15 G.SKILL • •
G.SKILL F2-5400PHU2-2GBNT 2G(kit of 2) DS D2 64M8CCF 0815 C7173S 5-5-5-15 G.SKILL • •
GEIL GX21GB5300SX 1G DS Heat-Sink Package 3 GEIL • •
GEIL GX22GB5300LX 2G DS Heat-Sink Package 5 GEIL • •
HY HYMP 512U64CP8-Y5 AB 1G DS HY5PS12521CFP-Y5 5 Hynix • •
Kingmax KLCD48F-A8KB5 1G DS KKEA88B4LAUG-29DX N/A Kingmax • •
Kingston KVR667D2N5/1G 1G DS
SO1280420822 SOP D6408TR4CGL25U
SL156304PECXA
N/A Kingston • •
Kingston KVR667D2N5/2G 2G DS E1108ACBG-8E-E 0813A90CC N/A Elpida • •
Nanya NT1GT64U8HB0BY-3C 1G DS NT5TU64M8BE-3C72155700CP 5 Nanya • •
PSC AL7E8F73C-6E1 1G SS A3R1GE3CFF734MAA0J 5 PSC • •
Qimonda HYS64T128020EU-3S-B2 1G DS HYB18T 512B00B2F3SFSS28171 5 Qimonda • •
Samsung M378T5263AZ3-CE6 4G DS K4T2G084QA-HCE6 N/A Samsung • •
Super Talent T667UB1GV 1G DS PG 64M8-800 0750 5 Super Talent • •
Transcend JM667QLJ-1G 1G DS E5108AJBG-6E-E 5 Elpida • •
Twinmos 8D-A3JK5MPETP 512MB SS A3R12E3GEF633ACAOY 5 PSC • •
ELIXIR M2Y1G64TU8HA2B-3C 1G DS M2TU 51280AE-3C717095R28F 5 ELIXIR • •
Leadmax LRMP 512U64A8-Y5 1G DS HY5PS12821CFP-Y5 C 702AA N/A Hynix • •
1-6 ASUS M4N78-AM V2
