ix
M4N78-AM V2 specifications summary
USB Supports up to 10 USB 2.0/1.1 ports (6 ports at mid-board,
4 ports at the back panel)
LAN Broadcom B5071 PHY Gigabit LAN
ASUS special features ASUS Turbo Key
ASUS Q-Fan
ASUS CrashFree BIOS3
ASUS EZ Flash2
ASUS AI NET2
ASUS MyLogo2
ASUS overclocking
features
SFS (Stepless Frequency Selection):
- Memory tuning from 533MHz to 1066MHz
- PCIe frequency tuning from 100MHz to 200MHz at
1MHz increment
ASUS C.P.R. (CPU Parameter Recall)
Back panel I/O ports 1 x PS/2 Keyboard port
1 x PS/2 Mouse port
1 x RJ45 port
1 x VGA port
4 x USB 2.0/1.1 ports
6-channel audio I/O ports
1 x COM port
1 x LPT port
Internal I/O connectors 3 x USB 2.0/1.1 connectors support additional 6 USB 2.0/1.1
ports
1 x IDE connector
4 x SATA connectors
1 x system panel connector
1 x CD audio-in connector
1 x Internal speaker connector
1 x Front panel audio connector
1 x CPU fan connector
1 x S/PDIF_OUT connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
BIOS 8Mb Flash ROM, AMI BIOS, PnP, DMI v2.0, WfM2.0,
ACPI v2.0a, SM BIOS v2.5
Accessories 2 x Serial ATA cables
1 x Ultra DMA 133/100/66 cable
1 x I/O shield
1 x User Manual
Form Factor MicroATX form factor: 9.6 in x 8.0 in (24.4 cm x 20.3 cm)
Support DVD Drivers
ASUS Update
ASUS PC Probe II
Anti-Virus software (OEM version)
*Specifications are subject to change without notice.
