Chapter 1: Product introduction
Chapter 1
1.2.5
Expansion slots
Unplug the power cord before adding or removing expansion cards. Failure to do so may
cause you physical injury and damage motherboard components.
Slot No. Slot Description
1
PCIe 2.0 x1_1 slot
2
PCIe 3.0/2.0 x16_1 slot
3
PCIe 2.0 x1_2 slot
4
PCIe 2.0 x1_3 slot
5
PCIe 3.0/2.0 x16_2 slot
6
PCIe 2.0 x1_4 slot
7
PCIe 3.0/2.0 x16_3 slot
