ix
Z87-EXPERT specifications summary
CPU LGA1150 socket for the 4th Generation Intel ® Core™ i7/Intel ®
Core™i5/ Intel ® Core™ i3, Pentium ® and Celeron ® processors
Supports 22nm CPU
Supports Intel
® Turbo Boost Technology 2.0*
* The Intel ® Turbo Boost Technology 2.0 support depends on the CPU
types.
Chipset Intel ® Z87 Express Chipset
Memory 4 x DIMM, max. 32GB, DDR3 2800 (O.C.)* / 2666 (O.C.)* / 2600
(O.C.)* / 2500 (O.C.)* / 2400 (O.C.)* / 2200(O.C.)* / 2133(O.C.)* / * / 2500 (O.C.)* / 2400 (O.C.)* / 2200(O.C.)* / 2133(O.C.)* / / 2500 (O.C.)* / 2400 (O.C.)* / 2200(O.C.)* / 2133(O.C.)* / * / 2400 (O.C.)* / 2200(O.C.)* / 2133(O.C.)* / / 2400 (O.C.)* / 2200(O.C.)* / 2133(O.C.)* / * / 2133(O.C.)* / / 2133(O.C.)* / * / /
2000 (O.C.)�� �� 1866(O.C.)�� �� 1800(O.C.)�� ��1600 �� 1333 MHz, non- �� �� 1866(O.C.)�� �� 1800(O.C.)�� ��1600 �� 1333 MHz, non- �� 1866(O.C.)�� �� 1800(O.C.)�� ��1600 �� 1333 MHz, non- �� �� 1800(O.C.)�� ��1600 �� 1333 MHz, non- �� 1800(O.C.)�� ��1600 �� 1333 MHz, non- 1800(O.C.)�� ��1600 �� 1333 MHz, non- 1600 �� 1333 MHz, non-
ECC, un-buffered memory
Dual channel memory architecture
Supports Intel
® Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Please refer to Memory QVL (Qualified Vendors List)
for details.
Expansion slots 3 x PCI Express 3.0/2.0 x16 slots (support x16, x8/x8, x8/x4/x4
mode)
4 x PCI Express 2.0 x1 slots*
* Thunderbolt port shares bandwidth with PCIe x1�2/4 slots. The Thunderbolt port shares bandwidth with PCIe x1�2/4 slots. The
Thunderbolt port default runs at X4(Auto) mode for system resource
optimization. Go to Advanced> Onboard Devices Configuration>
Thunderbolt bandwidth in BIOS to configure the bandwidth to [X2] for
PCIe x1�2/4 support.
VGA Integrated Graphics Processor - Intel ® HD Graphics support
Multi-VGA output support: HDMI/DVI-D/RGB/Thunderbolt port Thunderbolt port port
Supports HDMI with max. resolution of 4096 x 2160 @24Hz and
2560 x 1600 @60Hz
Supports DVI with max. resolution of 1920 x 1200 @60Hz
Supports RGB with max. resolution of 1920 x 1200 @60Hz
Supports Thunderbolt Interface* with max. resolution of 4096 x
2160@24Hz �� 3840 x 2160@60Hz
Supports Intel ® InTru™ 3D, Intel ® Quick Sync Video, Intel ® Clear
Video HD Technology, and Intel ® Insider™
Supports up to three displays simultaneously
Maximum shared memory 1024MB
* DisplayPort 1.2 Multi-Stream Transport compliant, supports
DisplayPort 1.2 monitor daisy chain up to 3 displays.
Multi-GPU support Supports NVIDIA ® Quad-GPU SLI™ Technology (with 2 PCIe x16
graphics cards)
Supports AMD ® 3-WAY/Quad-GPU CrossFireX™ Technology
LAN Intel ® I217-V Gigabit LAN - Dual interconnect between the integrated LAN
controller and physical layer (PHY)
(continued on the next page)
