ix
P7H55-V specifications summary
(continued on the next page)
CPU LGA1156 socket for Intel ® Core™ i7/ Core™ i5/ Core™ i3
/ Pentium ® processors
Supports Intel ® Turbo Boost Technology
* The Intel ® Turbo Boost Technology support depends on CPU
types
** Refer to www.asus.com for Intel ® CPU support list.
Chipset Intel ® H55 Express Chipset
Memory Dual-channel memory architecture
4 x 240-pin DIMM slots support maximum 16GB unbuffered
non-ECC DDR3 2200*(O.C.)/2133 /1866 /1800/1600
/1333/1066 /MHz memory modules
* To achieve DDR3’s frequency of 2200MHz, use an Intel Core
i7/Core i5 CPU withouth the iGPU feature and install a VGA
card. If you use Intel Core i5/Core i3/Pentium CPU with the
iGPU feature, the maximum frequency is around 1600MHz.
** Supports Intel ® Extreme Memory Profile (XMP)
*** Hyper DIMM support is subject to the physical
characteristics of individual CPUs. Some hyper DIMMs only
support one DIMM per channel.
**** Refer to www.asus.com for the latest Memory QVL
(Qualified Vendors List).
***** When you install a total memory of 4GB or more,
Windows ® 32-bit operating system may only recognize less
than 3GB. We recommend a maximum of 3GB system
memory if you are using a Windows ® 32-bit operating
system.
Expansion slots 1 x PCI Express™ 2.0 x16 slot
3 x PCI Express™ 2.0 x1 slots (2.5GT/s, gray slots)
3 x PCI slots
Graphics Multi-VGA output support: HDMI and RGB ports
Supports HDMI with max. resolution 1920 x 1200 @60Hz
Supports RGB with max, resolution 2048 x 1536 @75Hz
Maximum shared memory of 1748MB
Storage Intel ® H55 Express Chipset:
- 6 x SATA 3.0 Gb/s connectors
VIA ® VT6415 PATA controller:
- 1 x Ultra DMA 133/100/66 connector for up to 2 PATA
devices
LAN Realtek ® RTL8111E Gigabit LAN controller featuring AI NET2
Audio ALC887 8-channel High Definition Audio CODEC
- Optical S/PDIF out port at mid-board and back I/O
- Supports Jack-detection and Multi-streaming
* Use the chassis with HD audio module in the front panel to
support 8-channel audio output.
