Page 31
ASUS Terminator Barebone System
31
3.2 USB/Audio Board Layout
The USB/audio board is located on the front panel to support externally
accessible connectors including two USB, headphone, and
microphone connectors.
®
USB2P
MIC2
USB
T: Port0
B: Port1
MIC
LOUT
LO2
UAEX
Front Panel
Connectors
Connect to USB1 Connector
on the Motherboard
Connect to FLOUT Lead
on the Motherboard
Connect to MIC2 Lead
on the Motherboard
