Fiber Tap HD8
7
Specifications
Splitter Specifications
Fiber Type 10 Gigabit model:
Corning Multimode 50 or 62 .5/125µm, wavelength 850nm
Split Ratio Network Port Insertion Loss Monitor Port Insertion Loss
50/50 ≤ 4.5 dB ≤ 4.5 dB
70/30 ≤ 2.4 dB ≤ 6.3 dB
Fiber Type 10 Gigabit model:
Corning Singlemode 8 .5/125µm, wavelength 1310nm or 1550nm
Split Ratio Network Port Insertion Loss Monitor Port Insertion Loss
50/50 ≤ 3.7 dB ≤ 3.7 dB
70/30 ≤ 2.0 dB ≤ 6.1 dB
Fiber Type Gigabit model:
Corning Multimode 50 or 62 .5/125µm, wavelength 850nm
Split Ratio Network Port Insertion Loss Monitor Port Insertion Loss
50/50 ≤ 4.5 dB ≤ 4.5 dB
70/30 ≤ 2.4 dB ≤ 6.3 dB
Fiber Type Gigabit model:
Corning Singlemode 8 .5/125µm, wavelength 1310nm
Split Ratio Network Port Insertion Loss Monitor Port Insertion Loss
50/50 ≤ 3.7 dB ≤ 3.7 dB
70/30 ≤ 2.0 dB ≤ 6.1 dB
Environment
Operating Temperature: 0˚C to 40˚C
Storage Temperature: -55˚C to 85˚C
Relative Humidity: 10% min, 95% max, non-condensing
Mechanical
Dimensions: 0 .875” high x 7” deep x 17” wide
Connectors
(8) Duplex LC connector (monitor port)
(8) Quad LC connectors (network ports)
