GigaBit Fiber Port Aggregator Tap
2
• Passes all traffic (including errors) from all layers for comprehensive
troubleshooting
• No IP address is needed for the Tap or monitoring device, enhancing moni-
toring security
• Redundant power ensures monitoring uptime
• Fully RoHS compliant
Ease of Use
• LED indicators show redundant power, speed, link, and activity status
• Front-mounted connectors support easy installation and operation
• Silk-screened application diagram illustrates all connections for easy
deployment
• Optional 19-inch rack frames hold up to two Taps
• Small form-factor pluggable (SFP) monitor port connectors increase
monitoring options
• Tested and compatible with all major manufacturers’ monitoring devices,
including protocol analyzers, probes, and intrusion detection/prevention
systems
Support
• Net Optics offers free technical support throughout the lifetime of your
purchase (and has done so since our start in 1996!) . Our technical support
team is available from 8 am to 5 pm Pacific Time, Monday through Friday
at +1 (408) 737-7777 and via email at ts-support@netoptics .com . FAQs are
also available on Net Optics website at www .netoptics .com .
Unpacking and Inspection
Carefully unpack the GigaBit Fiber Port Aggregator Tap and check for dam-
aged or missing parts . The Port Aggregator Tap ships with the following:
• GigaBit Fiber Port Aggregator Tap with SFP Monitor Ports
• Two SC to SC fiber cables
• Two power supplies (AC power models)
• Installation Guide
In addition to the Port Aggregator, you should have ordered one or two Giga-
Bit SFP modules . You may have also ordered an extended warranty . Carefully
check the packing slip against parts received . If any part is missing or dam-
aged, contact Net Optics' Customer Service immediately .
