GigaBit Fiber In-Line Regeneration Taps
7
Specifications
Environment
Operating.Temperature:.0˚C.to.40˚C
Storage.Temperature:.-10˚C.to.70˚C....
.
Relative.Humidity:.10%.min,.95%.max,.non-condensing
Power
Power.Supply.Input:.100-240.VAC,.0 .5A,.47-63Hz.
Input:.-48V.DC.typical,.-36V.DC.min,.-75V.DC.max
Mechanical
Dimensions:.1 .75”.high.x.10 .5”.deep.x.17”.wide
Certifications
Fully.RoHS.compliant.
Optical Interface
Transceivers:.Class.I,.eye-safe,.laser.emitter.type ..These.Class.I.Lasers..
conform.to.the.applicable.requirements.per.US.21.CFR.(J).and..
EN.60825-1,.also.UL.1950.applications .
Multimode (SX):
....Split.Ratio:.50/50,.70/30
Cable.Type:.Multimode.Corning.50.or.62 .5/125µm,.wavelength.850nm
Insertion.Loss:.Network.Port:.≤. 4 .5.dB
.
Monitor.Port:.≤. 4 .5.dB
Optical.Transmitter.Wavelength:.850.nm.nominal.
Output.Power:.-9 .5.dB.min,.-4.dB.max.
Optical.Receiver.Input.Sensitivity:.0.dB.min,.-17.dB.max
Singlemode (LX):
Cable.Type:.Singlemode.Corning.8 .5/125µm,.wavelength.1310nm
Insertion.Loss:.Network.Port:.≤. 3 .7.dB.
.
.Monitor.Port:.≤. 3 .7.dB
Optical.Transmitter.Wavelength:.1310.nm.nominal.
Output.Power:.-10.dB.min,.-3.dB.max.
