Q-Tech QT625L - Manual (Page 2)

THIS DOCUMENT IS CONSIDERED PROPRIETARY TO Q-TECH CORPORATION
DO NOT COPY OR DISTRIBUTE WITHOUT Q-TECH CORPORATION APPROVAL
51774 A
SHEET 1 of 5
CAGE CODE SIZE SCALE:
NONE
P.Steinblums
DATE RELEASED BY
REV.
F
DRAWING NO.
QT625L
M.Dao
DATE CHECKED BY
HYBRID CRYSTAL OSCILLATOR +3.3V,
CLASS S, DETAIL SPECIFICATION FOR
C.Hooper
DATE PREPARED BY
UNLESS OTHERWISE
SPECIFIED DIMENSIONS ARE
IN INCHES.
TOLERANCES:
3 PLACE DECIMAL = .005
2 PLACE DECIMAL = .02
1 PLACE DECIMAL = .1
FRACTIONS = ± 1/16
ANGLES = 2 DEGREES
Q-TECH CORPORATION
10150 W. JEFFERSON BLVD.
CULVER CITY, CA. 90232-3510
SPECIFICATION CONTROL DRAWING
Update paragraph 3.3.3.1. Update Table III and notes to Figure 1. F
C.Hooper 5/08/09 Correction to Figure 1. E
E.Jackson 8/08/08 Change to microcircuit manufacturer, paragraph 3.3.3 D
7/17/07 Modify paragraph 3.3.3 for clarification of microcircuit technology, SEL rating C
3-19-07 Clarify temperature stability definitions, Table I. B
2-27-07 Modify tr/tf spec limits to better reflect output buffer drive capability. A
Initial release -
APPROVED DATE DESCRIPTION REVISION
REVISIONS
