THIS DOCUMENT IS CONSIDERED PROPRIETARY TO Q-TECH CORPORATION
DO NOT COPY OR DISTRIBUTE WITHOUT Q-TECH CORPORATION APPROVAL
51774 A
SHEET 1 of 5
CAGE CODE SIZE SCALE:
NONE
10/15/08 M.Dao
DATE RELEASED BY
REV.
A
DRAWING NO.
QT606C
10/9/08 T.Villegas
DATE CHECKED BY
HYBRID CRYSTAL OSCILLATOR +5V, CLASS S,
DETAIL SPECIFICATION FOR
10/6/08 E.Jackson
DATE PREPARED BY
UNLESS OTHERWISE
SPECIFIED DIMENSIONS ARE
IN INCHES.
TOLERANCES:
3 PLACE DECIMAL = .005
2 PLACE DECIMAL = .02
1 PLACE DECIMAL = .1
FRACTIONS = ± 1/16
ANGLES = 2 DEGREES
Q-TECH CORPORATION
10150 W. JEFFERSON BLVD.
CULVER CITY, CA. 90232-3510
SPECIFICATION CONTROL DRAWING
E.Jackson 10/06/08 Change to microcircuit manufacturer, paragraph 3.3.3.1. Update frequency range, Table III A
Initial release -
APPROVED DATE DESCRIPTION REVISION
REVISIONS
