MIL-PRF-55310/20F
2
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Mounting: See figure 1.
Pads: See figure 1.
Seal: Hermetic in accordance with
MIL-PRF-55310 , maximum leakage rate 5 x 10 -8 atm cc/s.
Weight: 4 grams, maximum.
Oscillator: Class 2 or any class 1 or class 3 oscillator meeting all class 2 requirements and verification tests
specified herein and in
MIL-PRF-55310 .
Calibration: Manufacturer calibrated.
Screening: In accordance with MIL-PRF-55310 , product level B or S, as applicable.
Temperature:
Operating: See table I.
Storage: -62
°C to +125°C.
Oscillator load: Standard TTL loads (see table I).
Output waveform: Symmetrical square wave.
Output voltage:
Logic 1: 2.4 V dc, minimum.
Logic 0: 0.5 V dc, maximum.
Rise and fall times: See table I.
Duty cycle: See table I.
Supply voltage: 5.0 V dc
±10 percent.
Input current: At designated supply voltage (see table I).
Output frequency: Frequency as designated at time of acquisition (see table I).
Initial accuracy at reference temperature (up to 30 days after shipment): See table I.
Initial frequency-temperature accuracy (one-half temperature cycle): Verification applicable. 1/
Frequency-temperature tolerance (one-half temperature cycle, referenced to frequency measured at +23
°C ±1°C,
immediately prior to starting of the test): See table I. Measurements taken at ten equally spaced increments over
the specified operating temperature range. 1/
1/ For the purpose of transitioning this device to
MIL-PRF-55310 , ‘Frequency stability versus temperature’ has been
renamed ‘Frequency-temperature tolerance’. The verification requirements of ‘initial frequency-temperature
accuracy (one-half temperature cycle)’ shall apply except that frequency measurements shall be referenced to
the frequency measured at +23
°C ±1°C (f
ref
) instead of to the nominal frequency (f
nom
).
