SINE WAVE SOURCES
DUAL-IN-LINE CRYSTAL CLOCK OSCILLATORS
5.0 to 15Vdc - 10Hz to 450MHz
Q-TECH
CORPORATION
Sine Wave Sources (Revision E, August 2010 ) (ECO# 9936)
Vcc
Out
GND
QT906S
QT941S
QT957S
+5Vdc
OUTPUT
0.01µF
50
Vcc
Out
GND
QT901S
+15Vdc
OUTPUT
0.01uF
1k
Vcc
Out
GND
QT901S(<500Hz)
+15V
OUTPUT
0.01µF
1k
1µF
Output Waveform into 50Ω load Test Circuit
Startup Time
Typical output amplitude and start-up time of QT957S-20.0166MHz
Typical spectrum output power and harmonics of QT957S-171MHz
Typical output amplitude of QT957S-69.4MHz
