SCANTECH ID (Champtek company) Pollux P-4010 User Manual

Page 5

background image

Table of contents

Preface

i

Chapter 1

The Pollux P-4010

1

1.1 Unpacking the Pollux P-4010

2

1.2 Scanning bar codes with the Pollux P-4010

4

1.3 Scanner labelling

6

1.4 Maintaining the scanner

9

1.5 Controlling the scanner from the POS system

9

Chapter 2

Installing the Pollux P-4010

11

2.1 Installing the scanner on a counter surface

13

Chapter 3 Mounting options Pollux P-4010

17

3.1 Flyby mode scanning: right to left

19

3.2 Flyby mode scanning: left to right

21

3.3 Presentation mode scanning 2

3

Appendices A. Connector types and pin definitions

26

B. Technical specifications

28

C. Troubleshooting

30
