7. Place the scanner on the vertical mount as illustrated in the figure.
8. Reposition the back cover of the scanner.
9. Power on the scanner by connecting the IEC power cord to the AC/DC power
supply and plugging the AC power cord into an AC power outlet. Switch on
the host system.
Once the scanner is installed, you can start scanning bar code labels. If you
want to change the default settings of the scanner, proceed to the Configuration
Guide which came with the scanner.
16 Installing the Pollux P-4010
AUX INTERFACE INTERFACE POWER PORT 2 PORT 1
SCANNER FRONT
■ To activate Data port 2 (OCIA or KBW interface), follow this sequence:
1. Plug in the appropriate interface cable and then power up the scanner.
2. Scan the following codes from the Configuration Guide:
- Open the scanner Programming Mode by scanning code 1.1
- Return to factory default settings by scanning code 1.3
IMPORTANT
