18 Mounting options Pollux P-4010
The ability to turn the optical assembly of the Pollux provides a large number of
mounting options. This chapter will help you find the best mounting option for
your application. (For information on turning the optical assembly, please refer
to the Pollux Service Manual. Authorized personnel only).
The Pollux P-4010 can be installed:
- fixed on a counter surface
or
- sunk into the counter surface
.
Your choice depends on the way you intend to use the scanner.
The following pages illustrate which mounting options are available.
To install the Pollux in flyby mode for scanning from Right to Left, please refer to
Section 3.1
To install the Pollux in flyby mode for scanning from Left to Right, please refer to
Section 3.2
To install the Pollux in presentation mode, please refer to Section 3.3
