C>Setup HID Slave Mode
HID Slave Mode
To setup the communication between the scanner and
Bluetooth HID profile application device, follow the
steps.
1)
The scanner must scan “HID Slave Mode”
barcode to set the scanner in HID slave mode.
2) When control the Bluetooth device to search the
scanner, enter pin code to setup pairing. You can
scan number barcode on Appendix D
, “Decimal
Value Table II
” number 0~9, to setup.
3) When scanner is successful connected, scanner
blue LED will also blink with up-tone. Blue LED
will slowly flash to finish the setup.
7.2 Out of Range
When “Out of Range” function is enabled, and the
scanner is working at out of transmission range, the
scanned data will be stored to out-of-range memory.
Memory size is approximately 25,000 sets of EAN13
barcode type. The all stored data will be transmitted to
device when the link is reconnected, and the all data
stored in out-of-range memory will be cleared.
Out of Range Disable
67
