5.10 Code 11 Parameters
A> Check Digit Transmission
Check Digit>
%0 L N 3
Calculate Check 1
Digit & Transmit
Calculate Check 2 Digits
& Not Transmit
%0 L N 7
%0 L N 5
Calculate Check 2
Digits & Transmit
%0 L N 6
Calculate Check 2 Digits
& Not Transmit
% 0 L N 4
B> Set Up Code Length
To set the fixed length:
1. Scan the
“Begin“ label of the desired set.
2. Go to the Decimal Value Tables in Appendix A,
scan label(s) that represents the length to be
read.
3. Scan the
“Complete“ label of the desired set.
Repeat the steps 1 - 3 to set additional lengths.
40
