5.7 Matrix 25 Parameters
A> Check Digit Transmission
% 0 I N 3
Calculate Check Digit
& Transmit
% 0 I N 7
Calculate Check Digit
& Not Transmit
% 0 I N 5
B> Set Up Code Length
To set the fixed length:
1. Scan the
“Begin“ label of the desired set.
2. Go to the Decimal Value Tables in Appendix A,
scan label(s) that represents the length to be
read.
3. Scan the
“Complete“ label of the desired set.
Repeat the steps 1 - 3 to set additional lengths.
34
