Appendices

24

A.

CONNECTOR TYPES AND PIN DEFINITIONS


Mica supports multiple interface: RS232, KBW (Keyboard Wedge), USB, and
Powered USB. The various pin definitions for each type of interface are given below.

IMPORTANT

Various interface cables are available depending on the kind of
host system you are using. Contact your supplier for
availability. In case you need a special purpose cable, you can
refer to the information below.


The Connector type of Mica: RJ-48, 10 pins.

Pin Definition for multiple interface

Multiple Interface

RS-232 KBW

USB/

Powered USB

Pin Description

Description Description

Remark

1 -

-

IFID IFID=Interface

ID

2 CTS PC-Clock -

3 RxD PC-Data

-

4 TxD

IFID=Interface

ID

5 RTS KB-Clock -

6 Ground Ground Ground

Ground

7 +5.2V +5.2V +5.2V

5.2V, may be used to

power scanner

8 D-Power D-Power D-Power

8-16V DC input

to power scanner*

9 -

IFID: connect

to ‘6’

D +

IFID=Interface ID

D + = USB data

10

-

D -

D - = USB data

*Mica only requires one single DC input.
