Mica M-9030

9

Exterior View

Cable cap

Open to change the

interface cable.

Window

LED/Speaker cap

Cover locks
Secure the window cover.

NOTE

Mica beeps whenever data has been read correctly. Both frequency
and volume can be adjusted (see section 2.1.1 Speaker frequency
and 2.1.2 Speaker volume on the Configuration Guide).

2.2

CONNECTING


Interface Selection
Mica allows you to connect your host system using four different interface cables:
RS232, Keyboard Wedge, USB, and Powered USB. On powering up, the scanner
senses the type of the interface used and switches to the appropriate protocol.

Interface Cable

Connector type

RS232 (Product Number: 0114-SM01121)

Sub-D 9-pin

Keyboard Wedge (Product Number: 0114-SM02121)

Standard PS2
