UAD Powered Plug-Ins Manual - 99 - Chapter 9: DreamVerb
Screenshot
Signal Flow
Figure 37 illustrates the signal flow for DreamVerb. The input signal is equal-
ized then delay lines are applied to the early reflection and late field gener-
ators. The resulting direct path, early reflection, and late-field reverberation
are then independently positioned in the soundfield.
Figure 36. The DreamVerb plug-in window
Figure 37. DreamVerb signal flow
Late-
Field
Reverb
EQ
Source
Input
Early
Reflections
Direct Path
Pan
Pans &
Distance
Gain Output
Delay
Delay
Wet/Dry
Mix
Gain &
Mute
