16
Small Block Ford Tru Trac - 13605 / 13625 17
Figure 11: Install Power Steering Bracket & Pump
If your kit does not include power steering proceed to Figure 12.
A] Place power steering bracket onto timing cover. Thread the two
3/8-16 x 1-1/4” socket head cap screws into bracket and tighten.
B] Attach power steering pump to bracket with two 5/16-24 x 3” socket head
cap screws and 5/16” split washers and tighten firmly.
Figure 12: Install Crank Damper
At this time install the 4-bolt damper
and tigthen firmly.
A
B
Figure 13: Install Coupler Spacer & Stud
A] Apply anti-seize to the 3/8-16 x 1-1/4” threaded stud and thread into the top
passenger side ear of the timing cover & tighten.
B] Apply anti-seize to the exposed threads. Disassemble the tensioner coupler
assembly and thread the long spacer nut onto stud and tighten.
A
B
